AA190EA01 Technical Data

Enabling Customer Innovation to Empower Tomorrow's Technology

AA190EA01 (Alias: T-55699D190J-LW-A-AAN) is a 19.0" diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 1.0G (9.8 m/s2). It's general features are summarized in the following: Ultra High Brightness, WLED Backlight, Life ≥ 100K hours, Upside I/F, 180° Reverse, 6/8 bit, Matte , NCM. Based on its features, we recommend that this model be applied to Industrial, Outdoor High Brightness etc.

Technical Data:

Part #：

AA190EA01

Brand：

MITSUBISHI ELECTRIC

Size：

19.0 inch"

Resolution：

1280×1024

Interface：

19.0 inch

Technology：

Transmissive

Brightness：

1500 cd/m2 (Typ.)

Operating Tem：

-20 ~ 70 °C

Storage Tem：

-30 ~ 80 °C

Name

Telephone

Touch screen customize: YesNo

Cover Glass customize: YesNo

Demo Kits: YesNo

Message

Integrated Display solutions

Touch screen, standard ready-made and customization

Supportrting capacitive touch screen (I2C interface, SPI interface, USB interface, UART interface)/ resistive touch screen / touch structure and function customization / optical bonding manufacturing.
Specific features:
High cost effective, automotive grade, industrial grade, medical grade solutions.
Durable and sturdy design for extreme environments.
Supports glove touch, multi touch, and stylus touch.
Featuring waterproofing, salt water resistance, low reflectivity, and 3D gesture touch control .

Driver board/adapter board, standard ready-made and design customization

DEMO board, HDMI board, other customized board, etc

Embbed Integrated Solution

UART display solution, HMI display solution, WINDOW display solution, Android display solution, Raspberry Pi solution, portable secondary screen solution, etc.
